    General Vessel Mooring UHMWPE Fiber Rope Customized Length None Water Absorption

    56mm x 220m double braided uhmwpe fiber rope mooring line for ship


    Material: UHMWPE/Polyester


    GIRO MAX PLUS is the high end jacketed rope composed of a consruction of an independent 12 strand GIRO MAX core and high tenacity sheath of polyester. This double braided rope has higher strength, greater abrasion and UV resistance, lower stretch and creep than GIRO MAX, which makes it ideal for all kinds of mooring aplications.


    DIACIRLinear DensityMBL(KN)
    MMINCHKtexUnsplicedSpliced
    81424944.1
    121-1/28910291.8
    162167182163.8
    182-1/4211231207.9
    202-1/2240271244
    222-3/4290341307
    243340402362
    263-1/4400471424
    283-1/2460549494
    303-3/4530537573
    324600736662
    344-1/4680824742
    364-1/2770912821
    384-3/48501010909
    40594011401030
    445-1/2115013801240
    486135016101450
    526-1/2160019201730
    567185021901970
    607-1/2212025202270
    648240028802590
    688-1/2272032602930
    729307036303270
    769-1/2340040203620
    8010375045104060
    8811450053504820
    9612530062805650

    Main Performance


    Fiber(core/cover)UHMWPE/Polyester
    Meiting point150℃/265℃
    Elongation at brcak4-5%
    Water AbsorptionNone
    U.V.resistanceGood
    Abrasion resistanceVery good
    High strength
    lowest elongation
    Dry & wet conditionswet strength equals dry stength
    Non-rotating and anti-kinking
    Long life and essy handing
    Range of use/Use scopefishery,marine,engineering,mooring,tugboat
    Coil length220m (length can be customized)
    Spliced strength10%
    Weight and length tolerance5%
    Mbl-Minimum Breaking Loadconform iso 2307
    Other sizes available upon request
